| General Product Information |
Insulating material |
PA |
|
Inflammability class acc. to UL 94 |
V2 |
|
Packing Unit |
4 |
|
Weight (g) |
— |
| Dimensions |
Width |
48 mm |
|
Length |
108 mm |
|
Height (MR 32) |
58.5 mm |
|
Height (MR 35×7.5) |
54 mm |
| TSE / CE Technical Data |
Nominal Voltage |
1000 V ~ |
|
Nominal Current |
309 A |
|
Cross Section |
150 mm2 |
|
Norm |
EN 60947-7-1 |
| VDE Technical Data |
Nominal Voltage |
— V ~ |
|
Nominal Current |
— A |
|
Cross Section |
— mm2 |
|
VDE Norm |
— |
| UL / CSA Technical Data |
Nominal Voltage |
— V ~ |
|
Nominal Current |
— A |
|
Cross Section |
— |
| ATEX Technical Data |
Nominal Voltage |
— V ~ |
|
Nominal Current |
— A |
|
Cross Section |
— |
| Connection Data |
Minimum solid strand cross section |
150 mm2 |
|
Maximum solid Strand cross section |
150 mm2 |
|
Minimum fine Strand cross section |
150 mm2 |
|
Maximum fine strand cross section |
150 mm2 |
|
AWG Conductor Range |
300 KCMIL/150 mm² |
|
Connection Type |
screw/vidalı |
|
Insulation Stripping length |
— mm |
|
Tightening torque |
— Nm |
