| General Product Information |
Insulating material |
PA |
|
Inflammability class acc. to UL 94 |
V2 |
|
Packing Unit |
25 |
|
Weight (g) |
|
| Dimensions |
Width |
20 mm |
|
Length |
80 mm |
|
Height (MR 32) |
81.70 mm |
|
Height (MR 35×7.5) |
84.70 mm |
| TSE / CE Technical Data |
Nominal Voltage |
1000 V ~ |
|
Nominal Current |
150 A |
|
Cross Section |
50 mm2 |
|
Norm |
EN 60947-7-1 |
| VDE Technical Data |
Nominal Voltage |
— V ~ |
|
Nominal Current |
— A |
|
Cross Section |
50 mm2 |
|
VDE Norm |
— |
| UL / CSA Technical Data |
Nominal Voltage |
600 V ~ |
|
Nominal Current |
150 A |
|
Cross Section |
AWG/6-1/0 |
| ATEX Technical Data |
Nominal Voltage |
800 V ~ |
|
Nominal Current |
150 A |
|
Cross Section |
— |
| Connection Data |
Minimum solid strand cross section |
16 mm2 |
|
Maximum solid Strand cross section |
70 mm2 |
|
Minimum fine Strand cross section |
25 mm2 |
|
Maximum fine strand cross section |
50 mm2 |
|
AWG Conductor Range |
6-0 |
|
Connection Type |
screw/vidalı |
|
Insulation Stripping length |
20 mm |
|
Tightening torque |
6 Nm |
|
|
