| General Product Information |
Insulating material |
PA |
|
Inflammability class acc. to UL 94 |
V2 |
|
Packing Unit |
20 |
|
Weight (g) |
— |
| Dimensions |
Width |
6 mm |
|
Length |
53.5 mm |
|
Height (MR 32) |
— mm |
|
Height (MR 35×7.5) |
50.5 mm |
| TSE / CE Technical Data |
Nominal Voltage |
500 V ~ |
|
Nominal Current |
16 A |
|
Cross Section |
4 mm2 |
|
Norm |
EN60947-7-1 |
| VDE Technical Data |
Nominal Voltage |
— V ~ |
|
Nominal Current |
— A |
|
Cross Section |
4 mm2 |
|
VDE Norm |
— |
| UL / CSA Technical Data |
Nominal Voltage |
600 V ~ |
|
Nominal Current |
16 A |
|
Cross Section |
4 |
| ATEX Technical Data |
Nominal Voltage |
— V ~ |
|
Nominal Current |
— A |
|
Cross Section |
4 |
| Connection Data |
Minimum solid strand cross section |
0.5 mm2 |
|
Maximum solid Strand cross section |
6 mm2 |
|
Minimum fine Strand cross section |
1.5 mm2 |
|
Maximum fine strand cross section |
4 mm2 |
|
AWG Conductor Range |
26-10 |
|
Connection Type |
screw/vidalı |
|
Insulation Stripping length |
10 mm |
|
Tightening torque |
0.5/0.8 Nm |
