| General Product Information |
Insulating material |
PA |
|
Inflammability class acc. to UL 94 |
V2 |
|
Packing Unit |
100 |
|
Weight (g) |
— |
|
Continuouse Operating Temp. |
80 °C (min.-max.) |
|
DIN-EN 45545Z |
EN 60998-2-1 |
| VDE Technical Data |
Nominal Voltage |
450 V ~ |
|
Nominal Current |
57 A |
|
Cross Section |
6 mm2 |
|
VDE Norm |
EN 60998-2-1 |
| UL / CSA Technical Data |
Nominal Voltage |
450 V ~ |
|
Nominal Current |
57 A |
|
Cross Section |
10-6 |
| Connection Data |
Minimum solid strand cross section |
6 mm2 |
|
Maximum solid Strand cross section |
16 mm2 |
|
Minimum fine Strand cross section |
6 mm2 |
|
Maximum fine strand cross section |
10 mm2 |
|
AWG Conductor Range |
10-6 |
|
Connection Type |
screw/vidalı |
|
Insulation Stripping length |
7,5 + 1 mm |
|
Tightening torque |
0.4 Nm |
| SK Dimensions |
L |
174,5 |
|
W |
25.0 |
