| General Product Information |
Insulating material |
PA |
|
Inflammability class acc. to UL 94 |
V2 |
|
Packing Unit |
10 |
|
Weight (g) |
|
| Dimensions |
Width |
20 mm |
|
Length |
80.00 mm |
|
Height (MR 32) |
— mm |
|
Height (MR 35×7.5) |
77.00 mm |
| TSE / CE Technical Data |
Nominal Voltage |
— V ~ |
|
Nominal Current |
— A |
|
Cross Section |
50 mm2 |
|
Norm |
EN 60947-7-2 |
| VDE Technical Data |
Nominal Voltage |
— V ~ |
|
Nominal Current |
— A |
|
Cross Section |
20 mm2 |
|
VDE Norm |
IEC 60947-7-1/IEC60947-7-2 |
| UL / CSA Technical Data |
Nominal Voltage |
— V ~ |
|
Nominal Current |
— A |
|
Cross Section |
AWG 6-1/0 |
| Connection Data |
Minimum solid strand cross section |
16 mm2 |
|
Maximum solid Strand cross section |
70 mm2 |
|
Minimum fine Strand cross section |
25 mm2 |
|
Maximum fine strand cross section |
50 mm2 |
|
AWG Conductor Range |
6-0/16-50 |
|
Connection Type |
screw/widalı |
|
Insulation Stripping length |
24 mm |
