| General Product Information |
Insulating material |
PA |
|
Inflammability class acc. to UL 94 |
V2 |
|
Packing Unit |
50 |
|
Weight (g) |
|
| Dimensions |
Width |
12 mm |
|
Length |
50.0 mm |
|
Height (MR 32) |
— mm |
|
Height (MR 35×7.5) |
55.5 mm |
| TSE / CE Technical Data |
Nominal Voltage |
750 V ~ |
|
Nominal Current |
76 A |
|
Cross Section |
16 mm2 |
|
Norm |
EN 60947-7-1 |
| VDE Technical Data |
Nominal Voltage |
750 V ~ |
|
Nominal Current |
76 A |
|
Cross Section |
16 mm2 |
|
VDE Norm |
IEC 60947-7-1 |
| UL / CSA Technical Data |
Nominal Voltage |
600 V ~ |
|
Nominal Current |
85 A |
|
Cross Section |
AWG/12-4 |
| ATEX Technical Data |
Nominal Voltage |
630 V ~ |
|
Nominal Current |
66 A |
|
Cross Section |
16 |
| Connection Data |
Minimum solid strand cross section |
1.5 mm2 |
|
Maximum solid Strand cross section |
16 mm2 |
|
Minimum fine Strand cross section |
1.5 mm2 |
|
Maximum fine strand cross section |
16 mm2 |
|
AWG Conductor Range |
12-4 |
|
Connection Type |
screw/vidalı |
|
Insulation Stripping length |
16 mm |
|
Tightening torque |
1.2 Nm |
|
|
